ROLPIN ECO-ROLAY
Rolpin ROLAY and ECO are plywoods made of MARITIME PINE (French origin). Used for furnishings, furniture, carpentry, construction and packaging.
Format: 2500 x 1250 mm
The Plus :
– Decorative panels
– NF Exterior CTB-X Structure
– Environmentally friendly
Options:
Cutting and machining on request
Where to find this product?
See the two sides above:
Product features
| Face | Closed face, with healthy knots and wood pellets (max. 8/m²). Occasional mastic repairs |
| Counterface | Open face, not repaired, admitting knotholes and cracks |
| Finish | The 2 faces are sanded |
Features
Standards
Read more
Features
| Dimensions | 2500 x 1250 mm (other formats on request) |
| Thicknesses | From 7 to 38 mm |
| Packing | From 85 to 15 |
| Density | 560 to 610 kg/m3 |
| Uses | Fittings, furniture, carpentry and construction works. |
| Collage | According to EN 314-2: bonding class 3 “outdoor environments”, water and weather resistant. Phenolic glue. |
| Options | Cutting and machining on request. |
Standards
| Structural jobs in construction | System 2+ certificate of conformity according to EN 13986 + A1 |
| Outdoor environments | According to EN 636 + A1 (structural use). Approved to the French quality mark NF Extérieur CTBX and to the German mark BFU 100 DIN 68705 part 3. |
| Release of formaldehyde | Classification E1 According to EN 717.2 Formaldehyde emission measurements show a release of 0.02 mg/l of air according to the ISO 12460-4 desiccant method. This value is 15 times lower than the requirements of the Japanese standard F****, the most stringent in the world (0.3 mg/l) according to JIS A 1460 |
| Reaction to fire classification | According to EN 13501-1 + A1 Thickness > 9 mm : Euroclass D-s2, d0 |
| CE marking | n° 380 – CPD – 011 – EN 13986 + A1 |
Read more
Storage | It is advisable to store the packages in a dry place, preferably flat and level on dry rafters insulating them from the ground. The spacing between rafters is to be adapted to the thickness and nature of the stored panels. When storing in multiple stacks, align the rafters in height. On site, provide shelter or cover the panels with a waterproof but vapor permeable coating. |
| Implementation | Comply with the rules of the art, safety and the DTU in force. |
| Dimensional tolerances of the panels | They comply with the specifications of standard EN 315: – Length/width dimensional tolerance: ±3.5 mm – Straightness of edges and squareness: 1 mm per linear meter – Thickness tolerance according to NF EN 315 |
| Other features | Thermal conductivity Biological durabilityPentachlorophenol content Water vapor permeability Acoustic Absorptionλ = 0,13W/.K Maritime pine species : Class 3 – 4 according to EN 350 part 2 < 5 ppm. (PCP) 70 μ wet / 200 μ dry 250 to 500 Hz = 0.10 1000 to 2000 Hz = 0.30 |
For more information and to consult the mechanical characteristics, download the data sheet available below.
